GS insPIRe U MAX Cold Storage Panels

NEW! Polyisocyanurate Panels

GS insPIRe®  U MAX cold storage panels are designed for external curtain walls and internal partition walls in skeletal structures. The panels can be installed both vertically and horizontally as single and multi-span wall elements.

Product of

Cold Storage Panels

Hidden fastening, invisible from the facade, makes these cold storage panels very attractive in terms of architecture and functionality. The plate cladding is galvanized steel sheet on both sides according to EN 10346 with organic polyester varnish with a coating thickness of 25 μm. The tightness of panel joints is ensured by the PUS polyurethane gasket applied at the production stage.cold storage panels

  1. The profiling of the metal cladding makes the walls look aesthetically pleasing
  2. Hidden fastening connector giving the façades a more uniform appearance
  3.  A large radius of profiling of the lock ensuring the integrity of the protective coatings
  4. Double lock connecting the panels guaranteeing high fire integrity properties
  5. Auxiliary groove for easy positioning of the fastening connector
  6. Contoured edges facilitate assembly and increase thermal insulation
  7. Continuous polyurethane gasket maintaining high thermal insulation. It was applied during the production process
  8. Aluminum foil prevents water vapor from entering the polyurethane foam core
  9. Core made of rigid PIR foam with very good thermal insulation and fire properties

Technical Information

Type of core Modified PIR
Declared heat transfer coefficient λD [W/m*K] 0.019
Thickness [mm] 60 80 100 120 140
R value 14.9 21.8 28.4 35.5 40.6
*Mass [kg/m^2] 11.3 12.1 12.9 13.7 14.5
Maximum length [m] 16.5
Total width [mm] 1050
Modular width [mm] 1000
**Exterior lining profiles for 1000 mm modular widths L - Linear, M - Microfiltered, F - Wavy, R - Grooved, P - Flat
Interior lining profiles L - Linear, P - Flat
**Standard exterior lining colors for 1000mm modular widths RAL 3000 RAL 5010 RAL 6011 RAL 7016 RAL 7035
RAL 8017 RAL 9002 RAL 9006 RAL 9007 RAL 9010
**Standard interior lining colors RAL 9002 RAL 9010
***Fire resistance classification for MAX panels
Reaction to fire Bs-1, d0
Fire spread Non Fire Spreading
Certificates, approvals, seals of approval DWU CE according to EN 14509 - Certificate of Business Continuity EN 14509

* Weight per 1 m b. for lining 0.5 / 0.5 mm (width for 1140). Detailed masses in files for download.

** Available colors depend on lining thickness

*** Conditions in accordance with the fire resistance classification. Details of the division of fire resistance in the horizontal and vertical arrangement in Declaration of performance

Profiles

Downloads

Leaflet_Sandwich Panels

DoP(EN), GS PIR U MAX, nr.2020_2
